SKU: ZP84940
UPC: 4957812585811
Linked to MusiPos
RRP: $699.99
Stock:
1 — Primary Warehouse
0 — Secondary Warehouse
Description
FM synthesizer: Discover new/genuine FM
Features
Features
Sound

4-operator FM Sound Engine offers dynamic and expressive additive synthesis
A new feature of this engine is continuously variable feedback on every operator allowing for a wide-range of sound creation
Two programmable effects blocks with seven effect types per block:
The effect types are: VCM Touch Wah, VCM Flanger, VCM Phaser, Chorus, Delay, Reverb and Distortion
Multi-touch control interface gives direct access to four simultaneous parameters
32 Voice memory locations allow storing and recalling favorite Voices
Control

Based on the FS action found on the flagship Motif XF, HQ (High Quality) Mini Keys provide premium feel and response for fast, accurate and natural playing
Integrated Phrase Looper: capture song ideas or just jam
Sustain pedal input allows the sustain function for all FM generated sounds
Mobility & Connectivity

2W 3cm stereo speaker system lets you play any place, any time
Specially designed bass reflex port technology enhances bass response for full, rich sound
Battery powered - uses six "AA" batteries with five hours of life
USB "TO HOST" allows MIDI connectivity to your USB-equipped computer or iOS device
Dual 1/4"unbalanced line outputs provide connection to mixers, audio interfaces, DI boxes and more
A 3.5mm aux line input lets you connect and hear mobile devices, tablets and more through the instrument
Create your Soundmondo. Inspire and be inspired.

Soundmondo is a free sound sharing community that lets you discover, create and share reface Voices and Set Lists using Google Chrome any place, any time youre online.
Powered by Web MIDI, Soundmondo is simple to use - just connect reface to Chrome and youre ready to create or start browsing.
reface inside
Specifications
Specs
Amplifiers and Speakers
| Amplifiers | 2 W x 2 | |
|---|---|---|
| Speakers | 3 cm x 2 | |
Power Supply
| Power Consumption | 6 W (When using PA-130 power adaptor) | |
|---|---|---|
| Battery Life | Approximately 5 hours | |
| Auto Power Off | Yes | |
| Power Supply | Adaptors | PA-130 or an equivalent recommended by Yamaha |
| Batteries | Six “AA” size batteries or Ni-MH rechargeable batteries | |
Accessories
| Included | AC adaptor*, MIDI breakout cable, Owner’s Manual, Warranty* *May be included depending on your locale | |
|---|---|---|
Voices
| Number of types | 4 Operators, 12 Algorithms | |
|---|---|---|
| Number of voices | 32 (memorable) | |
| Effects | Distortion/VCM Touch Wah/Chorus/VCM Flanger/VCM Phaser/Delay/Reverb | |
Size/Weight
| Dimensions | Width | 530 mm (20 7/8") |
|---|---|---|
| Height | 60 mm (2 3/8") | |
| Depth | 175 mm (6 7/8") | |
| Weight | 1.9 kg (4 lbs, 3 oz) (not including batteries) |
Keyboard
| Number of Keys | 37 keys | |
|---|---|---|
| Type | HQ mini (High-Quality mini) | |
| Initial Touch | Yes | |
Tone generation
| Maximum Polyphony | 8 | |
|---|---|---|
| Engine | FM | |
Other Features
| Phrase Looper | Yes | |
|---|---|---|
| Display | Type | Full Dot LCD (128 x 64 dots) |
Connectivity
| DC IN | DC IN (12 V) jack | |
|---|---|---|
| Headphones | PHONES (6.3 mm, stereo phone jack) | |
| MIDI | MIDI (mini-DIN IN/OUT) | |
| AUX IN | AUX IN (3.5 mm, mini stereo phone jack) | |
| OUT PUT | L/MONO, R (6.3 mm, TS phone jack, unbalanced) | |
| USB TO HOST | USB (TO HOST) | |
| Pedal | Type | SUSTAIN: FC3(A), FC4(A), FC5 (optional) |
| Half damper | NO (*Half damper's control message can be sent to external device via MIDI) | |
- SKU
- ZP84940
- Barcode
- 930042019737
- Brand
- Yamaha
