M2 Features

•     Stereo 32-bit float recorder
•     Newly designed stereo X/Y microphones provide unmatched frequency response and clarity
•     Body construction and specialized finish to reduce handling noise
•     LCD screen with waveform display
•     Easy-to-use front panel controls
•     Mono mode for ENG application
•     Onboard Normalization function
•     3.5mm headphone output
•     Includes a newly designed mic clip to mount on a mic stand
•     USB Microphone compatible with PC, Mac, iOS, and Android (48 kHz at 24 or 32-bit Float**)
•     Use as a USB microphone and record to SD card simultaneously
•     Runs on 2 AA batteries* (11 hour battery life)

* Batteries not included
** For Android, 32-Bit Float cannot be used with USB Microphone
Specs
Inputs
Built-in mic     90º XY stereo format
    Directionality     Unidirectional
    Sensitivity     −42 dB/1 Pa at 1 kHz
    Maximum sound pressure input     135 dB SPL

Outputs
PHONE/LINE OUT jack     Connector     Stereo mini jack
    Maximum output level     20 ｍW + 20 ｍW (into 32Ω load)
    Output impedance     10 Ω or less
Built-in speaker         500mW 8Ω mono speaker

Recorder
Recording format     WAV
    44.1/48/96 kHz, 32-bit float
    Stereo/mono
    BWF and iXML formats supported
Recording media     4–32GB cards compatible with the microSDHC specification
    64GB–1TB cards compatible with the microSDXC specification

Display
    96×64 LCD with backlight

USB
Connector     USB Type-C
    • Use a USB cable that supports data transfer.
USB Mic     USB 2.0 High Speed
    48 kHz
    24-bit or 32-bit float
File transfer     USB 2.0 High Speed

Power
2 AA batteries     Alkaline, Lithium, or Rechargeable NiMH
AC adapter     ZOOM AD-17: DC 5 V/1 A
    • USB bus power is supported.

Estimated Continuous Operation Time Using Batteries
Alkaline batteries     About 11 hours
NiMH batteries (1900 mAh)     About 10.5 hours
Lithium batteries     About 22 hours


Stereo recording, 48kHz/32-bit float, no headphones, display backlight off
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.
They will vary greatly according to use conditions.
Power consumption     5 W maximum
Dimensions     221.5 mm (W) × 61.9 mm (D) × 59.3 mm (H)
Weight (including batteries)     204 g


Note: 0 dBu = 0.775 Vrms

Here’s what’s included:

M2 MicTrak
Windscreen
Mic Clip
Quick Tour

Optional M2 accessories:

WSU-1 Universal Windscreen
SMC-1 Stereo Mini Cable
TPS-4 Tripod Mic Stand
AD-17 Power Adapter
ZHA-4 Headphone Amplifier
