Description

There may never have been an amp boasting such a lofty and pure sound in the entire history of VOX. The VOX Hand-Wired Series relies on the painstaking technique of turret board hand-wiring – a method requiring a high level of skill and craftsmanship – is used, resulting in wiring that's beautiful in its artistry, ensuring an efficient signal path with minimal loss and no restriction in amplitude. In the Hand-Wired Series, tubes, transformers, speakers, chassis, and custom parts all join together in an ideal state to deliver the richest and most powerful sonic experience – the ultimate amp. Not bound by tradition, the VOX Hand-Wired Series also provides a variety of new functions that keep pace with the needs of today's artists. Offering a rich variety of tonal shadings and a broad model lineup, the enormous potential of the VOX Hand-Wired Series will reveal itself in any musical scenario. Available models:   AC30HWH 30 Watt Hand-Wired Head   V212HWX: 30 Watt Cabinet, 2 x 12" Celestion Alnico Blue Speakers

Features



Manual
Hand-Wired AC15, AC30 & V212
AC15_30HW_V212HWX_OM_EFGS2.pdf

Owner's Manual for Hand-Wired AC30HW2(X), AC15HW1(X), AC30HWH, and V212HWX


Specifications

VOX Hand-Wired Series Specificaitons

AC30HWH

Output Power: 30 Watts RMS into 8/16 Ohms

Tube Complement: Preamp: ECC83/12AX7 (x3), Power amp: EL84 (x4), Rectifier: GZ34

Inputs: NORMAL Channel Jacks: HIGH (x1); LOW (x1) TOP BOOST Channel Jacks: HIGH (x1); LOW (x1) FOOT SWITCH Jack

Outputs: POWER OUTPUT Jacks (x2 for external/extension speakers)

Dimensions (W x D x H): 705 x 260 x 250 mm / 27.76 x 10.24 x 9.84 inches

Weight: 18.8 kg / 41.5 lbs.

Included items: Power cable, VFS1 footswitch, Dust cover, High-performance VOX custom speaker cable

V212HWX

Speakers: 12” 8 Ohm Celestion Alnico Blue (x2); Total 30W 16 Ohm.

Dimensions (W x D x H): 705 x 260 x 550 mm / 27.76 x 10.24 x 21.65 inches

Weight: 20.3kg / 44.8 lbs.

Included items: Dust cover

SKU
VOX-AC30HWH
Barcode
930011020380
Brand
Vox

Please Note: This item may be on display at the Mooloolaba Music Shop and may have been available for demonstration to in store patrons. We take careful and meticulous care, boxing and cleaning of your product before the shipping or selling of an item. If you do want photos before making a purchase please call our shop where one of our staff can assist in sending more detailed images.

Mooloolaba Music reserves the right to cancel, at any time before delivery and for whatever reason, an Order that it has previously accepted. Mooloolaba Music may do this for example, but without limitation, where:

a) Mooloolaba Music's suppliers are unable to supply Goods that they have previously promised to supply
(b) an event beyond Mooloolaba Music's control, such as storm, fire, flood, earthquake, terrorism, power failure, war, strike or failure of computer systems, means that Mooloolaba Music is unable to supply the Goods within a reasonable time
(c) Goods ordered were subject to an error on the Website, for example, in relation to a description, price or image, which was not discovered prior to the Order being accepted;
(d) The products shown in the images above product may differ to the purchased product. Changes could include, different stands, treatments, slight variations in colour, In-built batteries and charging ports. Please contact our team for further clarification.

We ask that you research parts carefully before buying.
Purchase of any non-licenced part as a replacement spare part is at your own risk.
Some branded replacement parts also require professional installation to fit correctly.
If in doubt we will be happy to advise further and confirm suitability before purchase.

Reviews

Vox

Vox Ac30Hwh 30-Watt Tube Guitar Amplifier Head

Read reviews · SKU VOX-AC30HWH
$2,599.00 RRP $3,199.00
Price includes GST


Currently sold out What's this?

The AC30HWH is an amplifier head only that provides 30 watts of power, features hand-wired circuitry and comes with a footswitch, cable and dust cover. This amplifier features an all-tube design using 3 x 12AX7 tubes in the preamp and 4 x EL84 vacuum tube
