Known as one of the most proficient and prolific bass players in extreme music, Steve Di Giorgio’s range extends out from heavy–thrash-death metal, progressing to the technical side of fusion and the fluid & funky field of jazz. While notably performing in Death and Testament, Steve has also established himself as an in-demand studio musician, as his technical and recognizable bass skills have been carved into over 50 albums in his 30 plus year career. When looking for a reliable bass that could adapt to any gig, Steve has trusted his Ibanez BTB models to do the job. So naturally, when designing a new signature model, Steve leaned heavily on many of the key BTB features as the framework for this bass. The final result is the combination of Ibanez’s modern innovations and Steve’s decades of experience – the SDGB.

Product Features

9pc Maple/Bubinga/Panga Panga neck with Graphite reinforcement rods
The 9-piece Maple/Bubinga/Panga Panga neck provides superior note attack, tight lows and increased sustain. The Graphite reinforcement rods provides massive sustain and excellent stability.

• Ebonol fretboard

Ebonol is a synthetic material which is made from layers of black paper and phenolic resin. An Ebonol fretboard provides tight and bright sound.

• Flamed Maple top / Ash / Okoume wing body

The Flamed Maple top displays a beautiful wood grain and the Ash/Okoume wing body delivers a pleasant brightness and rich sustain.

• Nordstrand Big Single pickups

Nordstrand ”Big Single” cram a meaty single coil into a soapbar-style pickup, producing a full-bodied, powerful, aggressive tonal texture, while still retaining the clarity that's characteristic of single coil pickups.

• Vari-mid 3-band EQ

The Vari-mid 3-band EQ features a variable mid-frequency control which allows you to dial in an incredibly wide range of sounds.

• Gotoh machine heads

Gotoh machine heads provide superior precision, a smooth feel, and excellent tuning accuracy.

• MR5 bridge

The Mono-Rail V is the ultimate bridge for bass string isolation. Each bridge is independently and securely locked down to the body for maximum vibration transfer without interference.

• EQ bypass switch (passive tone control on treble pot)

The EQ bypass control offers precision tonal adjustments, including a switch to choose passive-only operation. When the EQ bypass is activated, the treble tone control knob becomes the global tone control for the passive circuit.

• Luminescent side dots

The luminescent side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.

SPECIFICATIONS

•     neck type
•     SDGB9pc Maple/Bubinga/Panga Panga w/Graphite reinforcement rods Neck-through
•     top/back/body
•     Flamed Maple topAsh/Okoume wing body
•     fretboard
•     Ebonol fretboard
•     fret
•     Fretless
•     bridge
•     MR5 bridge
•     string space
•     19mm
•     neck pickup
•     Nordstrand Big Single neck pickup Passive
•     bridge pickup
•     Nordstrand Big Single bridge pickup Passive
•     equaliser
•     Vari-mid 3-band EQ w/ EQ bypass switch (passive tone control on treble pot)
•     factory tuning
•     1G,2D,3A,4E,5B
•     strings
•     D'Addario NYXL45130SL
•     string gauge
•     .045/.065/.080/.100/.130
•     hardware color
•     Cosmo black

NECK DIMENSIONS

        Scale: 889mm/35"
        a : Width = 47mm at NUT
        b : Width = 76mm at 24F
        c : Thickness = 20mm at 1F
        d : Thickness = 22mm at 12F
        Radius = 400mmR

DIMENSIONS
