DiMarzio® Air Norton™ / True Velvet™ / The Tone Zone® pickups

The DiMarzio® Air Norton™, True Velvet™ and Tone Zone® pickups offer depth, warmth and rich dynamics when combined with the 5-way pickup switch.

Ebony fretboard

Ebony produces tight lows and mid range with a strong attack in the high end and features a quick response and rich sustain.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

Oval C Roasted Maple neck

Heat-treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes.

Gotoh® T1502 tremolo bridge

The T1502 tremolo bridge features steel saddles and a die-cast zinc tremolo block for a quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm.

• SPECS

  • neck type
  • AZ Oval CRoasted Maple neck

  • top/back/body
  • Quilted Maple topAmerican Basswood body

  • fretboard
  • Ebony fretboardMother of Pearl dot inlay

  • fret
  • Jumbo Stainless Steel frets

  • number of frets
  • 24

  • bridge
  • Gotoh® T1502 bridge

  • string space
  • 10.5mm

  • neck pickup
  • DiMarzio® Air Norton™ (H) neck pickupPassive/Alnico

  • middle pickup
  • DiMarzio® True Velvet™ (S) middle pickupPassive/Alnico

  • bridge pickup
  • DiMarzio® The Tone Zone® (H) bridge pickupPassive/Alnico

  • factory tuning
  • 1E,2B,3G,4D,5A,6E

  • strings
  • D'Addario® EXL110

  • string gauge
  • .010/.013/.017/.026/.036/.046

  • nut
  • Graph Tech® nut

  • hardware color
  • Gold

• NECK DIMENSIONS

  • • Scale :
    • 648mm/25.5"
    • a : Width
    • 42mm at NUT
    • b : Width
    • 57mm at 24F
    • c : Thickness
    • 20.5mm at 1F
    • d : Thickness
    • 22.5mm at 12F
    • Radius :
    • 305mmR

  • OTHER FEATURES

    • Recommended Case
    • MR500C

    • Gig bag included

    • Gotoh® MG-T locking machine heads

    • Luminescent side dot inlay
