Roasted Maple neck

The Roasted Maple in the neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.

Roasted Maple fretboard

Heat-treatment provides a well-balanced attack and tone and a rich sustain. In order to achieve supreme neck grip comfort, the fretboard edge is finished with a smooth curve.

Jumbo frets

Jumbo frets contribute to smooth playability, especially for single-note playing.

Alder body

The Alder body delivers a well-balanced bright tone, enriched resonance and sustain.

DiMarzio® The Cruiser® /AT-1™ pickups

A DiMarzio® The Cruiser® in the neck position delivers single-coil tone, open vocal-sounding mids and a bit of added strength to the bass. A DiMarzio®AT-1™ in the bridge position gives excellent warmth and clarity, which balances well with the neck pickup.

Gotoh® MG-T locking machine heads

The Gotoh® MG-T locking machine heads achieve incredible tuning stability, cutting down string-changing time.

Wilkinson® WV6-SB tremolo

By utilising the unique Wilkinson "5+1" knife-edges, the Wilkinson® WV6-SB tremolo bridge offers unsurpassed "tone transfer" of a 6-screw pivot system with the smooth fulcrum action of a 2 pivot set-up.

Coil-tap switch

The coil tap switch adds sound and tonal variations for both pickups.

• SPECS

  • neck type
  • ATZRoasted Maple neck

  • top/back/body
  • Alder body

  • fretboard
  • Roasted Maple fretboardBlack dot inlay

  • fret
  • Jumbo frets

  • number of frets
  • 22

  • bridge
  • Wilkinson® WV6-SB bridge

  • string space
  • 10.8mm

  • neck pickup
  • DiMarzio® The Cruiser® (H) neck pickupPassive/Ceramic

  • middle pickup
  • DiMarzio® The Cruiser® (H) middle pickupPassive/Ceramic

  • bridge pickup
  • DiMarzio® AT-1™ (H) bridge pickupPassive/Ceramic

  • factory tuning
  • 1E,2B,3G,4D,5A,6E

  • strings
  • D'Addario® EXL110

  • string gauge
  • .010/.013/.017/.026/.036/.046

  • nut
  • Graph Tech® nut

  • hardware color
  • Chrome

• NECK DIMENSIONS

  • • Scale :
    • 648mm/25.5"
    • a : Width
    • 40.5mm at NUT
    • b : Width
    • 56.5mm at 22F
    • c : Thickness
    • 21mm at 1F
    • d : Thickness
    • 23mm at 12F
    • Radius :
    • 305mmR

  • OTHER FEATURES

    • Recommended Case
    • MR500C

    • Gig bag included

    • Gotoh® MG-T locking machine heads

    • Coil-tap switch

    • Luminescent side dot inlay
