-   26 x 30 USB-C recording interface with MAX-HD mic preamps and 32-bit / 192 kHz converters
-   Expanded Digital I/O: 16 ADAT channels, S/PDIF I/O, and ADAT preamp standalone mode
-   Front-facing Fender instrument inputs optimized for guitar and bass
-   Auto Gain button for fast and accurate recording levels
-   Re-amp outputs for creative tone experimentation
-   DSP monitor mixer and loopback routing for streaming and recording
-   Control preamps, phantom power, and outputs via Fender Studio Pro or Universal Control app
-   Professional software included: Fender Studio Pro perpetual license
-   Full-color high-resolution display with illuminated push encoder for intuitive operation
-   MIDI I/O and DC-coupled line outputs for modular synth control

Electronics
Headphone Jack: Two - 1/4" TRS Female Stereo
Connectivity: USB-C®
Voltage: 240V AUS
Phantom Power: +48 VDC

Performance
Digital Audio Bit Depth: 32-bit
Digital Audio Dynamic Range: 124 dB

Inputs
Instrument Inputs Dynamic Range: 111 dB (A-Weighted, Minimum Gain)
Instrument Inputs Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz)
Instrument Inputs Gain Range: 75 dB
Instrument Inputs Maximum Level: +21 dBu (Unbalanced, Minimum Gain)
Line Inputs Dynamic Range: 118 dB (A-Weighted, Minimum Gain)
Line Inputs Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz)
Line Inputs Gain Range: ± 10 dB
Line Inputs Impedance: 10K Ohms
Line Inputs Maximum Level: +18 dBu (Balanced, Minimum Gain)
Line Inputs Total Harmonic Distortion: 0.001% (1 kHz, Minimum Gain)
Microphone Input Connection Type: XLR Female (Combo), Balanced
Microphone Preamp Dynamic Range: 116 dB (A-Weighted, Minimum Gain)
Microphone Preamp Equivalent Input Noise: -130 dBu (Maximum Gain, 150 Ohms, 20 kHz BW, A-Weighted)
Microphone Preamp Frequency Response: 20 Hz to 20 kHz, +/- 0.1 dB (Unity Gain, Reference 1 kHz)
Microphone Preamp Gain Control Range: 75 dB
Microphone Preamp Input Impedance: 1600 Ohms
Microphone Preamp Maximum Input Level: +18 dBu (Balanced, Minimum Gain)
Microphone Preamp Total Harmonic Distortion: 0.002% (1 kHz, Minimum Gain)

Outputs
Headphone Outputs Connection Type
Headphone Outputs Dynamic Range: 118 dB (A-Weighted)
Headphone Outputs Frequency Response: 20 Hz to 20 kHz, +/- 0.3 dB (Unity Gain, Reference 1 kHz)
Headphone Outputs Impedance Working Range: 33 Ohms
Headphone Outputs Maximum Output: 11 dBu (50 Ohms)
Headphone Outputs Total Harmonic Distortion: 0.001% (1 kHz)
Line Outputs Connection Type: 1/4" TRS Female
Main And Line Outputs Dynamic Range: 123 dB (A-Weighted)
Main And Line Outputs Frequency Response: 20 Hz to 20 kHz, +/- 0.2 dB (Unity Gain, Reference 1 kHz)
Main And Line Outputs Maximum Level: +18 dBu (Balanced)
Main And Line Outputs Output Impedance: 51 Ohms
Main And Line Outputs Total Harmonic Distortion: 0.001% (1 kHz, +4 dBu)

Hardware
-    MIDI IO
-    5-Pin Female DIN
-    Word Clock IO
-    BNC Connector, 4.5 Vpp @ 75Ω Load

Measurements
Shipping Dimensions
15.24x30.48x60.96 CM
Shipping Weight
5.56 KG
Shipping Length
60.96 CM
Shipping Height
15.24 CM
Shipping Width
30.48 CM
Product Depth
8.6" (218 mm)
