Description

The EKX series is the newest member of the Electro-Voice portable loudspeaker family, andcombines legendary EV sound quality and reliability with the latest technology — all in acompact package suitable for a wide range of sound reinforcement scenarios, including musicians/DJs and live/club/installed sound applications. The EKX series features eight models (four powered and four passive), including 12-inch and 15-inch two-way models and 15-inch and 18-inch subwoofers.



Powered EKX models feature high-efficiency Class-D power amplifiers (up to 1500 W) with integrated QuickSmartDSP, and deliver up to 134 dB SPL utilizing high-sensitivity transducers designed and engineered by EV (12-inch EVS-12M woofer / 15-inch EVS-15M woofer, each coupled with a DH-1M 1-inch titanium compression driver; 15-inch EVS-15C subwoofer / 18-inch EVS-18C subwoofer).



The EKX amplifier incorporates intelligent thermal management (with a variable-speed fancontrolled by multiple onboard sensors) which ensures superior performance and reliability indemanding environmental conditions.



Powered models allow easy setup via four presets (Music, Live, Speech*, Club), sub/topsystem-match crossovers, three-band EQ*, five user-programmable presets (Store and Recallsettings), visual monitoring of limiter status, input level control* and meters, and mastervolume control to ensure optimal gain structure. (* not available on subwoofers)

Features

  • QuickSmartDSP features best-in-class processing, EV’s signature single-knob user interface, and intuitive menu navigation via LCD.
  • High-efficiency 1500 W Class D power amplifier delivers up to 134 dB peak SPL on the EKX-15P via high-sensitivity transducers designed and engineered by EV.
  • Intelligent thermal management with a variable-speed fan controlled by multiple onboard sensors, ensuring superior performance and reliability in demanding environmental conditions.
  • EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage.
  • Lightweight, compact 15-mm wood enclosure with internal bracing, durable EVCoat finish, eight M10 threaded mounting points, aluminum pole mounts, and all-metal handles.

Specifications

Frequency Response (-3 dB) 55 Hz - 18 kHz¹
Frequency Range (-10 dB) 48 Hz - 20 kHz¹
Maximum SPL 134 dB²
Coverage (H x V) 90" x 60"
Power Rating 1500 W
LF Transducer EVS-15M 381 mm (15 in)
HF Transducer DH-1M 1-inch titanium compression driver
Crossover Frequency 1.7 kHz
Connectors (1) Stereo RCA input, (2) XLR/TRS combo jack, and (1) XLR link output
Enclosure 15 mm plywood with EVCoat
Grille 18 AWG steel with powdercoat
Suspension (8) M10 threaded mounting points
Dimensions (H x W x D) 685 mm x 432 mm x 429 mm (27 in x 17 in x 17 in)
Net Weight 24.4 kg (53.9 lb)
Shipping Weight 29.5 kg (65.0 lb)
Power Consumption 1.8 A³



SKU
EVLEKX-15P
Model #
EVL-EKX-15P
Barcode
930077003461
Brand
Electro-Voice

Please Note: This item may be on display at the Mooloolaba Music Shop and may have been available for demonstration to in store patrons. We take careful and meticulous care, boxing and cleaning of your product before the shipping or selling of an item. If you do want photos before making a purchase please call our shop where one of our staff can assist in sending more detailed images.

Mooloolaba Music reserves the right to cancel, at any time before delivery and for whatever reason, an Order that it has previously accepted. Mooloolaba Music may do this for example, but without limitation, where:

a) Mooloolaba Music's suppliers are unable to supply Goods that they have previously promised to supply
(b) an event beyond Mooloolaba Music's control, such as storm, fire, flood, earthquake, terrorism, power failure, war, strike or failure of computer systems, means that Mooloolaba Music is unable to supply the Goods within a reasonable time
(c) Goods ordered were subject to an error on the Website, for example, in relation to a description, price or image, which was not discovered prior to the Order being accepted;
(d) The products shown in the images above product may differ to the purchased product. Changes could include, different stands, treatments, slight variations in colour, In-built batteries and charging ports. Please contact our team for further clarification.

We ask that you research parts carefully before buying.
Purchase of any non-licenced part as a replacement spare part is at your own risk.
Some branded replacement parts also require professional installation to fit correctly.
If in doubt we will be happy to advise further and confirm suitability before purchase.

Reviews

Electro-Voice

Electro Voice EKX-15P 2 Way Loudspeaker, 15" LF 1500W, Black

Read reviews · SKU EVLEKX-15P
$1,999.00 RRP $2,666.40
Price includes GST


Currently sold out What's this?
