SKU: EVLEKX-15
UPC: 800549783620
Linked to MusiPos
RRP: $1661
Stock:
0 — Secondary Warehouse
Description
The EKX series is the newest member of the Electro-Voice portable loudspeaker family, and combines legendary EV sound quality and reliability with the latest technology — all in a compact package suitable for a wide range of sound reinforcement scenarios, including musicians/DJs and live/club/installed sound applications. The EKX series features eight (8)models (four (4) powered and four (4) passive), including 12-inch and 15-inch two-way models and 15-inch and 18-inch subwoofers.
EV-engineered components, Signal Synchronized Transducers (SST) waveguide designprovides precise coverage and superior sound quality at high SPLs. award-winning industrialdesign — with robust wood enclosures and durable finish — ensures that EKX speakers look asgreat as they sound.
Passive EKX models deliver up to 134 dB SPL utilizing high-sensitivity transducers designedand engineered by EV (12-inch EVS-12M woofer / 15-inch EVS-15M woofer, each coupled witha DH-1M 1-inch titanium compression driver; 15-inch EVS-15C subwoofer / 18-inch EVS-18Csubwoofer).
EKX passive models are ideal for portable and installed applications, with lightweight and compact 15-mm wood enclosures with internal bracing, durable finish, eight (8) M10 threadedmounting points (full-range only), aluminum pole-mounts, and all-metal handles.
Specifications
| Frequency Range (-10 dB) | 50 Hz - 20 kkHz (Full Space Measurement) |
| Suspension | (8) M10 threaded mounting points |
| Minimum Impedance | 7.2Ω |
|
HF Transducer |
DH-1M 1-inch titanium compression driver |
| Speaker Type | Full-Range, two way |
| Woofer Size | 15inch |
| Powered or Passive | Passive |
| Frequency Response (-3 dB)¹ | 75 Hz - 18 kHz (Full Space Measurement) |
| Max. SPL/1m (calc)² | 132dB |
| Coverage (Nominal -6 dB) H | 90° |
| LF Transducer | EVS-15M 381 mm (15 in) |
| Coverage (Nominal -6 dB) V | 60° |
| Power Rating | 1600W |
| Crossover Frequency | 1.6 kHz |
| Connector Type | Dual NL4 |
| Enclosure Material | 15 mm, plywood with EVCoat |
| Grille | 18 AWG steel with powdercoat |
| Height | 685mm (26.97") |
| Width | 432mm (17.01") |
| Recommended High-Pass Frequency | 50Hz |
| Depth | 429mm (16.89") |
| Weight Net | 23.2kg (51.15 lbs) |
| Shipping Weight | 28.2kg (62.17 lbs) |
| Family | EKX |
| Passive Power Handling | 1600W peak |
| Nominal Impedance | 8Ω |
| Axial Sensitivity (SPL, 1 W @ 1 m) | 96dB (Full Space Measurement) |
| Power Handling (Continuous / Peak) | 400 W/1600W |
| Maximum SPL | 132dB (Maximum SPL is measured at 1 m using broadband pink noise at rated peak power rating) |
- SKU
- EVLEKX-15
- Model #
- EVL-EKX-15
- Barcode
- 930077003970
- Brand
- Electro-Voice
